Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher 500 X 500Mm Basket
2
Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher 500 X 500Mm Basket
2
Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher 500 X 500Mm Basket
2
Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher 500 X 500Mm Basket
Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher 500 X 500Mm Basket
Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher 500 X 500Mm Basket

Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher 500 X 500Mm Basket

Aristarco Pass-through dishwashers
Prices from
6614.06 +VAT
€8,135.29 inc vat
Earliest Possible Delivery is 03-04-2024 (4 Day)
Product Range
Info
Technical Details
Downloads
Videos
Info
Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher
Product Code: AH800ESPRS
SID: 16
Size (H x W x D)::
1494/1969 x 657/760 x 793
In Stock
RRP €7922.09
€6614.06 +VAT
Back Order Now
add
Technical Details
Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher
Fitted with Electronic controls, Break tank with booster pump, Inbuilt water softener, Detergent & rinse aid pumps
Basket size - 600 x 500mm - Max load height of 410mm - will take 600 X 400mm bakery or 1/1gn Trays
Dims; 657w/760w including handle x 793d x 1494h/1969h with hood open
Power; Elec 6.75kw 230v (32 amp) or 415v selectable on site (16amp supply)
Downloads
Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher
Videos
Aristarco AH800ES/PRS Energy Saver 18 Plate Hood Dishwasher
Description
This Aristarco AH800ES  WRAS approved Hood dishwasher is manufactured with an inbuilt heat recovery system which captures steam and uses that steam to preheat the incoming water, it is also fitted with a double skinned hood and body helping to reduce both Noise and Energy consumption. Fitted with Electronic controls, Green function during non washing cycles, Soft start wash pump function and detergent, rinseaid and drain pumps as standard.
Product Features
Basket size; - 500 x 500mm 18 plate capacity with a load height of 450mm - will take 1/1gn trays
Output - Upto 60 baskets/hour
Electronic controls with colour code switch
Choice of 4 washing cycles - Light (1. mins), STD ( 2 minutes), Heavy (3 mins) Intense (9 mins) -
Wash programs times can be adjusted to meet customer requirements
Forced drain function - this can be set to inform the operator when the water in the wash tank needs to be drained and refilled so always washing with clean water - ideal for heavy use sites
Cleaning function - at the end of the day an automatic cleaning cycle of the wash tanks takes place
Green function - puts the machine into standby when not being used
Water consumption per wash is 2 litres
Tank capacity = 22 litres with rinse boiler capacity of 5.5 litres
Fitted with thermostop - this only allows the machine to operate when the rinse and wash temperature are reached - this guarantees hygienic washing
Hot rinse
Cold water feed (between 10 & 50ºC) with a supply pressure between 2 and 5 bar
Inbuilt heat recovery system - Upto 50% saving in power - uses the steam during the wash & rinse cycles to preheat the incoming water supply to 45'C - it means no extraction hood is required
Inbuilt water softener - this can be set to suit the hardness of the water
Electric Detergent & Rinse aid pumps
Removable primary surface tank filters - collects larger items (forks, spoons etc) preventing them entering the wash tank
Plastic wash pump filter, protects the pump from risk of blockage - removable for cleaning
Self wash vertical pump
Component diagnosis - the engineer can test if all components are working correctly so reducing repair times
WRAS approved - Inbuilt break tank with rinse booster pump
Automatic end of day self cleaning of water tank
Soft start operation of wash pumps - increases pump life
Removable stainless steel wash and rinse arms to top and bottom
Automatic filling
Auto start/stop when lid is opened/closed
Anti back flow valve
Component diagnosis function - a service engineer can check which components need attention
304 Stainless steel Double skinned body and lid - reduces noise level and saves energy by reducing heat loss
316 Marine grade stainless steel boiler
Stainless steel wash and rinse arms - do not get brittle and crack like plastic ones
Preformed basket runners allow easy cleaning of the interior
